Photograph
Two Piece Trunnion
| William Rhody, a Falk employee, inspects a 2 piece trunnion. This particular unit was purchased by F.L. Smidth. Original Falk caption reads, "Trunnion-two piece design: both pieces are rough machined. The pieces are separated by two by fours showing the weld scarf before preparations are made for welding the two pieces together. Trunnions hubs: approximate rough weight 16,000 pounds, pattern number DXL-291-1, material ASTM A-27 Gr. 60-30 annealed. Trunnion Flange: approximate rough weight 28,000 pounds, pattern number DXL-291." |
| Image ID: | 50694 |
|---|---|
| Creation Date: | 09 22 1976 |
| Creator Name: | Unknown |
| City: | Milwaukee |
| County: | Milwaukee |
| State: | Wisconsin |
| Collection Name: | Falk Corporation photographs, 1954-1994 |
| Genre: | Photograph |
| Original Format Type: | negative, original |
| Original Format Number: | PH 6524, EG 48467 |
| Original Dimensions: | 10 x 8 inches |
| Original Falk negative number: EG 48467. Negative originally filed under the Foundry-Castings (Static) category at the Falk Corporation. |
| Factories |
| Machinery |
| Machinery industry |
| Metal industry |
| Men |
| This image is issued by the Wisconsin Historical Society. Use of the image requires written permission from the staff of the Collections Division. It may not be sold or redistributed, copied or distributed as a photograph, electronic file, or any other media. The image should not be significantly altered through conventional or electronic means. Images altered beyond standard cropping and resizing require further negotiation with a staff member. The user is responsible for all issues of copyright. Please Credit: Wisconsin Historical Society. |
| Location: | Wisconsin Historical Society Archives, 4th Floor, Madison, Wisconsin |
|---|
