Property Record
Riley Road over North Fork Jump River
Architecture and History Inventory
| Historic Name: | Riley Road Bridge (P-50-0091) |
|---|---|
| Other Name: | |
| Contributing: | |
| Reference Number: | 245701 |
| Location (Address): | Riley Road over North Fork Jump River |
|---|---|
| County: | Price |
| City: | |
| Township/Village: | Kennan |
| Unincorporated Community: | |
| Town: | 34 |
| Range: | 2 |
| Direction: | W |
| Section: | 2 |
| Quarter Section: | |
| Quarter/Quarter Section: |
| Year Built: | 1921 |
|---|---|
| Additions: | |
| Survey Date: | 2023 |
| Historic Use: | bridge |
| Architectural Style: | NA (unknown or not a building) |
| Structural System: | Warren Truss |
| Wall Material: | Metal |
| Architect: | |
| Other Buildings On Site: | |
| Demolished?: | No |
| Demolished Date: |
| National/State Register Listing Name: | Not listed |
|---|---|
| National Register Listing Date: | |
| State Register Listing Date: |
| Additional Information: | 2023: Structure P-50-0091 is a single-span pony truss bridge of riveted steel construction. It carries Riley Road across the north fork of the Jump River in a single north-south span. The one-lane bridge measures 60 feet in length, with a 20 foot-wide, cast-in-place concrete deck. The bottom chord is supported by steel floor beams, with timber abutments and angled timber wing walls. The bridge’s design is commonly referred to as a “Warren truss with verticals,” as vertical members bisect the equilateral triangles along the top chord. Members are held in place with both square-head and circular-head rivets. A steel pedestrian railing is located on the inside length of each elevation. pony truss bridge |
|---|---|
| Bibliographic References: | Files and construction records: P-50-0091. WisDOT Highway Structures Information System. |
